Hone Armored Tactical Fiber Optic Cable
The Hone Armored Tactical Fiber Optic Cable is designed for demanding field operations and complex environments. Its robust construction, featuring a spiral steel tube armor, ensures reliable performance even under harsh conditions. This pre-terminated cable offers ease of deployment and superior protection for the optical fibers within.
Description
This indoor armored tactical fiber cable incorporates both aramid yarn and a spiral steel tube for enhanced strength, making it ideal for applications requiring resistance to rodents. Multiple tight buffered fibers are securely protected within the cable sheath, further reinforced by the aramid yarn and spiral steel tube. The stainless steel spiral steel tube provides exceptional resistance to compression, tension, and rodent bites, allowing this tactical fiber cable to be deployed in a variety of challenging and complex wiring environments.
Applications
This cable is suitable for:
- Outdoor aerial installations
- Fiber to the Home (FTTH) deployments
Features
- Tight buffered optical fiber for easy stripping and operation
- Excellent flame retardant performance of the tight buffered fiber
- Aramid yarn strength member for superior tensile characteristics
- Stainless steel tube for added tensile and pressure strength
- Optional stainless steel woven mesh for increased tension and anti-rodent protection
- Small circular cable design for convenient laying
- Flexible operation with a good bending radius
Optical Characteristics
| Fiber Count | Cable Diameter (mm) | Crush Long/Short Term (N/100mm) | Tensile Long/Short Term (N) | Bending Radius Dynamic/Static (mm) | Attenuation 1310/1550nm (dB/km) | Attenuation 850/1300nm (dB/km) | Operation Temperature (°C) | Cable Weight (Kg/km) |
|---|---|---|---|---|---|---|---|---|
| 1 | 2.0/2.4 | 400/600 | 3000/4000 | 48D/24D | ≤0.4 | ≤0.3 | -40 ～ 80 | 7/9 |
| 2 | 2.8 | 400/600 | 3000/4000 | 48D/24D | ≤0.4 | ≤0.3 | -40 ～ 80 | 10 |
| 2 | 4 | 1200/1500 | 3000/4000 | 80D/40D | ≤0.4 | ≤0.3 | -40 ～ 80 | 28 |
| 4 | 4 | 1200/1500 | 3000/4000 | 80D/40D | ≤0.4 | ≤0.3 | -40 ～ 80 | 28 |
| 6 | 5 | 1200/1500 | 3000/4000 | 100D/50D | ≤0.4 | ≤0.3 | -40 ～ 80 | 32 |
Conclusion
The Hone Armored Tactical Fiber Optic Cable provides a robust and reliable solution for optical fiber deployments in challenging environments. Its armored construction and high-quality components ensure long-lasting performance and protection for critical communication links. This cable is an excellent choice for outdoor aerial installations and FTTH applications where durability and reliability are paramount.
