MPO Fiber Patch Cord Cable For High Density Data Cabling

Hone MPO/MTP Patch Cord

Hone MPO/MTP patch cords are fiber optic cables with Multi-Fiber Push On (MPO) connectors. Their compact design allows for high-density fiber connections, making them ideal for areas requiring integrated optical fiber lines.

Description

MPO fiber optic patch cords utilize MPO connectors. These patch cords can be configured with 2 to 12 fibers, and even up to 24 fibers, although 12-fiber MPO connectors are most common. The compact size of the MPO connector enables higher fiber density in a smaller space.

Application

MPO/MTP patch cords are suitable for:

High-density integrated optical fiber lines
FTTX applications
40/100GSFP, SFP+, and other transceiver modules
Internal and external equipment connections

Features

High precision MPO/MTP connector
Various cable structures available for different applications
Available in 4 to 48 core fiber cable with bundle and ribbon optical cable
Factory pre-termination for good transmission performance
Rapid configuration reduces installation time
Improves and simplifies fiber routing, saving fiber management space
Complies with IEC61754-7, Telcordia GR-1435-CORE, RoHS
OFNP and LSZH sheath materials available

Specifications

Connector Performance

Connector Type	Insertion Loss (dB)	500 times durability (dB)	Temperature Cycling (dB)
MPO/MPT MM Elite	≤0.35	≤0.20	≤0.20
MPO/MTP SM Elite	≤0.35	≤0.20	≤0.20
MPO/MTP MM Standard	≤0.70	≤0.20	≤0.20
MPO/MTP SM Standard	≤0.70	≤0.20	≤0.20

Cable Performance

Fiber Type	Core/Cladding Diameter (μm)	Bandwidth (MHz·km)	Wavelength (nm)	Max. Attenuation (dB/km)
G652D	9/125	NA	1310/1550	0.36/0.22
G657A2	9/125	NA	1310/1550	0.36/0.22
OM1	62.5/125	200	850/1300	3.0/1.0
OM2	50/125	500	850/1300	3.0/1.0
OM3	50/125	2000	850/1300	3.0/1.0
OM4	50/125	4700	850/1300	3.0/1.0
